Description
- Magnification Ratio: 1500X – 3000X
- Drawtube: BINOCULAR
- Material: Metal
- Model Number: B490B-M
- Brand Name: AmScope
- Theory: Biological Microscope
This is a professional binocular microscope with 1.3MP high quality digital camera. It is designed for teaching demonstration, clinical examination and research purpose. It comes with a 30 degree inclined 360 degree swiveling compensation free binocular head, 3D mechanical stage and an intensity-variable halogen illumination system. This microscope offers eight levels of magnification, 40X, 80X, 100X, 200X, 400X, 800X, 1000X & 2000X.
The digital camera captures still microscopy images, streams live videos on your computers, and is compatible with Windows XP/Vista/7/8, Mac OS X, and Linux. The 0.37X reduction lens included gives your computer screens the same field of view as your microscope’s eyepiece. The user-friendly software for Windows offers advanced features including Stitching, EDF (Extended Depth of Focus), video recording, and measurement functions. Live video and still image capture can be set in different resolutions simultaneously. You can edit and process images in a manner similar to PhotoShop.
This microscope is versatile, ready for various accessories and attachments for extra features. It is made by the same technicians and on the same production line that makes optical instruments for Leica, Zeiss, Nikon and Olympus. It is brand new in factory sealed box. Its retails is $2,200.
Microscope Features:
- 30-degree Inclined 360-degree Swiveling Compensation Free Binocular Head
- Large 3-D Double Layer Mechanical Stage with Stain Resistant Finish
- Low Position Coaxial Stage Movement Control Knobs
- Coaxial Coarse Fine Focusing with CA Knob Tension Control
- Fully Coated Optical System with High Resolution
- Crystal Clear Sharp Images
- High Quality Professional Grade Microscope
- Perfect for Clinics, Vets, Doctors, and Students.
- Eight Levels of Magnification: 40X-80X-100X-200X-400X-800X-1000X-2000X
- Upward Stage Stopper to Protect Slides and Objectives
- Abbe Condenser with Iris Diaphragm Filters
- Rack and Pinion Adjustment for Condenser
- Built-in Halogen Illumination System with Variable Intensity
- Dual Focusing Control Knobs
- Four DIN Achromatic Objectives
- Two Sets of Eyepieces
- Full Optical Glass Elements
- Precise Ground Glass Lenses
- All Metal Mechanical Components.
- Adjustable Interpupillary Distance
- Adjustable Diopter on Ocular
- Solid Metal Frame Construction with Stain Resistant Enamel Finish
- Spare Bulb, Fuse, and Included
- Manufactured Under ISO 9001 Quality Control Standard
- Excellent Five (5) Year Factory Warranty
Microscope Specifications:
- Nosepiece: quadruple
- Mechanical Tube Length: 6-5/16" (160mm)
- Head: 360-degree swiveling compensation free binocular head inclined at 30-degree
- Eyepieces: WF10X and WF20X
- Achromatic Objectives: 4X, 10X, 40X (spring), 100X (spring, oil)
- Stage Dimensions: 5-1/2"x 5-1/2" (140x140mm)
- Stage Traveling Range: 2-15/16"x 1-3/4" (75x45mm)
- Focusing Range: 1-3/16" (30mm)
- Division of Fine Focusing: 0.0000787" (0.002mm)
- Abbe Condenser: NA=1.25 with rack and pinion focusing control
- Illumination: 6V/20W halogen bulb
- Power Supply: 110V (220V version available), CE certified
- Accessories: 6V/20W spare halogen bulb, bottle of , blue, green yellow filters
Camera Specs:
- Sensor: Aptina MT9M111 CMOS (color)
- Sensor Size: 1/2" (6.66mm(H) x 5.32mm(V), diagonal 8.52mm)
- Resolution: 1280×1024 (approx. 1,310,000 pixels)
- Reduction Lens: 0.37X
- Pixel Size: 5.2µm x 5.2µm
- G Sensitivity: 2.1v / lux-sec (550nm)
- Frame Rate: 50fps @320×256, 26fps @640×512, 15fps @1280×1024
- Exposure: 0.14ms~2000ms, ROI Auto & Manual
- Operating System: Windows XP/Vista/7/8 (32 & 64 bit), Mac OS X, Linux
- PC Requirements: CPU equals to Intel Core2 2.8GHz or higher, USB2.0 port
- Advanced software for Windows:
– offers Stitching, EDF, video recording and measurement functions
– conducts measurements for lengths, angles, arcs, areas and etc.
– gives your computer screens the same field of view as your microscope’s eyepiece
– saves still images in BMP, TIFF, JPG, PICT, PTL or other formats
– edit and process microscopy images in a manner similar to PhotoShop
– live video and still image capture can be set in different resolutions simultaneously - Life-time free software upgrades
Packing List:
- One Binocular Compensation-Free Head
- One Microscope Body with Frame, Base and Halogen Illumination System
- Four High Quality DIN Objectives, 4X, 10X, 40X and 100X
- One Pair of Widefield WF10X Eyepieces
- One Pair of Widefield WF20X Eyepieces
- Two Color Filters
- One Dust Cover
- One 6V/20W Spare Halogen Bulb
- , Power Cord, Spare Fuses and User’s Manual Included
- One 1.3MP USB2.0 Digital Camera with Reduction Lens
- One 6′ (1.8m) USB Cable
- Two Adapters
- One CD with Software and User’s Instructions
- Shipping Weight: 22 lbs
