IR Infrared Transmitter and Receiver Module Kit for Arduino

IR Infrared Transmitter Module Specifications

• Supply Voltage: 5V
• Operating Temperature: -25°C to +85°C
• Storage Temperature: -30°C to +100°C
• Wavelength: 940nm
• Module Dimensions: 13.7mm x 27.8mm
• Module Weight: 1g
• Signal Type: Digital Signal
• Infrared Centre Wavelength: 850nm-940nm
• Infrared Emission Angle: Approximately 20 degrees
• Infrared Emission Distance: Approximately 1.3 meters (5V, 38kHz)

IR Receiver Module Specifications

• Adopts 1838 remote control receiver with high sensitivity
• Operating Voltage: 5V
• Output Form: Digital Output
• 2 fixing holes for easy installation (Aperture: 3.1mm)
• Data Indicator
• PCB Size: 23.5mm x 21.5mm

Wiring Instructions

1. DAT: Digital Output Interface
2. VCC: 5V DC Power Supply Positive
3. GND: 5V DC Power Supply Negative
