Product Features
- Utilises Infineon MCU and drive module with independent control board and high-torque AC/DC brushless motor.
- R404a refrigerant for wide temperature range (-20°C to 40°C) with pre-cooling, standby cooling, and defrosting functions.
- Advanced safety features: overspeed, overtemperature, imbalance, undervoltage, and overvoltage detection.
- TFT-LCD colour display and 10-step acceleration and deceleration rate control.
- Biological safety sealed angle rotor with silicone rubber seal (EU RoHS 2015/863 compliant).
- Austenitic 304 stainless steel centrifuge chamber and all-steel spray-painted plastic housing.
- Silent electric motor door lock system.
- Stores up to 100 user-defined programs.
Product Parameters
| Model | BC-HR20K |
|---|---|
| Max Speed | 20600 rpm |
| Max RCF | 29280 xg |
| Max Capacity | 6 x 250 ml |
| Default Rotor | 12 x 1.5/2.0 ml |
| Speed Precision | ±50 rpm |
| Refrigeration System | CFC-free refrigeration compressor unit (R404a) |
| Temperature Control Range | -20°C to 40°C |
| Temperature Precision | ±1°C |
| Running Programs | 20 sets |
