Key Features and Specifications
- Measuring Range: 0.05 ~ 18.25 MΩ; 0.5 ~ 200 uS/cm; 1 ~ 2000 uS/cm; 20 uS ~ 20 mS/cm
- Electrode Options: Plug-in electrode (0.01 cm-1) and quick-loading electrode (0.02 cm-1)
- Accuracy: < 1.5% (F·S)
- Display: Full-view LCD screen displaying conductivity, temperature, and mA values
Technical Specifications
| Parameter | Value |
|---|---|
| Medium Temperature | 0 ~ 60°C (normal temperature electrode); 0 ~ 120°C (high temperature electrode) |
| Medium Pressure | < 0.5 MPa |
| Temperature Compensation | Automatic compensation based on 25°C |
| Alarm Setting | Contact capacity: 3A/250V AC (resistive load) |
Environmental and Installation Details
- Power Supply: AC 220V ± 10%
- Environmental Conditions: Temperature 0 ~ 50°C; Humidity ≤ 80% RH
- Dimensions: 48 × 96 × 100 mm (height × width × depth)
- Installation Method: Panel mounted
