Our Diesel Engine Driven Horizontal Centrifugal Pumps feature a single-stage double suction split casing design, suitable for handling clean water or similar liquids with high capacity and pressure.
Key Features of the Diesel Engine Driven Horizontal Centrifugal Pump
High Capacity and Pressure
Single stage double suction split casing pump transmits clean water or similar liquids.
Technical Specifications
| Specification | Value |
|---|---|
| Pump Type | Split Casing Pump |
| Casing Material | HT200 |
| Impeller Material | SS304, SS316, Copper, HT200 |
| Pump Sealing | Packing seal, Mechanical seal |
| Capacity Range | 126m3/h~8520m3/h |
| Head Range | 8m~140m |
| Inlet/Outlet Diameter | 6″(150mm)~32″(800mm) |
| Rotary Speed | 1450rmp/2950rpm/585rpm/730rpm/970rpm |
| NPSH(r) | 2.5m~7.5m |
| N.Weight | 165kgs~2550kgs |
Applications
Various Industrial and Agricultural Uses
Construction, Industrial, Municipal, Agricultural, Mining, Dewatering, Industrial Waste, Sewage, Oil Field, Petrochemical, Paper Mills Processing.
