Product Overview
This handheld solar power meter is designed to measure solar irradiance, UV radiation, and IR radiation, making it an essential tool for various applications, including solar energy, laboratory research, and UV disinfection.
Key Features
- Broad spectral coverage across UV, visible, and IR spectrums
- Data hold and peak lock functions for dynamic measurements
- High-resolution digital display for clear visibility
- Flexible power ranges for high and low irradiance applications
- Optional waterproof probes for underwater measurements
Technical Specifications
| Model | Wavelength Range | Measurement Range | Resolution | Accuracy | Drift | Temperature Error | Display |
|---|---|---|---|---|---|---|---|
| SM206E-SOLAR | 360–1100nm | 0.1-1999.9 W/m² | 0.1 W/m² | ±(10%R+2dgt) | <±3%/year | ±0.38 W/m²/°C | 4½ digit LCD |
| SM206plus | 360–1100nm | 0.1-399.9 W/m², 1–3999 W/m² | 1μW/cm², 0.1Btu/(ft²·h) | ±(10%R+2dgt) | <±3%/year | ±0.38 W/m²/°C | 3¾ digit LCD |
Applications
The handheld solar power meter is suitable for various applications, including:
- Solar energy studies and panel transmittance testing
- UV lamp and disinfection light performance evaluation
- IR heater and medical device output monitoring
- Laboratory optics, meteorology, and greenhouse research
FAQs
Q1: Can I use this device to measure direct sunlight?
A: Yes, both SM206E-SOLAR and SM206plus are designed for direct solar irradiance readings.
