LCR-T4 Multifunction Component Tester
This device is designed for testing a wide range of electronic components, including resistors, capacitors, inductors, diodes, transistors, and SCRs. It features a high-resolution 128×64 LCD display with backlight for clear visibility.
Key Features
- Automatic detection of NPN and PNP transistors, N-channel and P-channel MOSFETs, diodes, thyristors, resistors, and capacitors
- Measurement of gate threshold voltage and gate capacitance of MOSFETs
- Detection of transistor amplification factor and base-emitter voltage
- High test speed: most components tested within 2 seconds
- Low power consumption: less than 20nA in shutdown mode
- Automatic shutdown to conserve battery life
Specifications
| Parameter | Value |
|---|---|
| PCB Size | 63 x 71 mm |
| Weight | approximately 48g |
| Power Supply | 9V battery or 2 x lithium batteries (8.4V) |
