LCR-T4 Multifunctional Component Tester
This high-precision tester is designed for laboratory and educational use, enabling users to accurately measure and test a wide range of electronic components.
Key Features:
- Automatic detection of NPN and PNP transistors, n-channel and P-channel MOSFETs, diodes, thyristors, triodes, resistors, and capacitors
- Measures capacitance (25PF–100MF), inductance, and resistance
- Displays component pin configuration on 12864 LCD display with backlight
- Tests transistor amplification factor, MOSFET protection diodes, and emitter transistor forward bias voltage
- Gate threshold voltage and gate capacitance measurement for MOSFETs
- High test speed: valid component test in 2 seconds (except larger capacitors)
- One-click operation and automatic shutdown to conserve battery life
- Power consumption off mode: less than 20 nA
Technical Specifications:
| PCB Size | 59.7*72.4 mm |
| Shell Size | 111.1*85.5 mm |
| Power Supply | 9V stacked battery or 8.4V lithium battery pack |
| Display | 12864 LCD with backlight (yellow-green) |
Safety and Quality:
Ensure accurate measurements and safe operation with this high-quality tester, designed with laboratory safety in mind.
