Key Features
- 3.5-inch 480*320 high-resolution TFT LCD screen with backlight
- 55,000 count resolution for precise measurements
- DC voltage accuracy up to 0.05%
- Dual-line display for simultaneous measurement display
- Fast measurement: up to 65 readings per second
- User-friendly interface with tabular data display
- Data record function: manual and auto record with up to 1,000 data points
- Temperature measurement with K-type temperature probe (not included)
- Replaceable fuse with anti-burn design for enhanced safety
- Multiple measurement functions: DC/AC voltage, DC/AC current, frequency, resistance, capacitance, True RMS, diode test, continuity, and temperature
Specifications
| Parameter | Specification |
|---|---|
| Display | 3.5-inch TFT LCD (480*320 resolution) |
| Max. Display | 55,000 counts |
| DC Voltage | 50mV~1000V |
| AC Voltage | 500mV~750V |
| DC Current | 500μA~10A |
| AC Current | 500μA~10A |
| Resistance | 500Ω~50MΩ |
| Frequency | 10Hz~60MHz |
| Capacitance | 50nF~50mF |
| Data Logging Duration | 15ms~9999.999s |
| Data Logging Length | 1,000 points |
Package Contents
- 1 x Digital Multimeter
- 1 x Pair of Test Leads
- 2 x Alligator Clips
- 1 x Spare Fuse
- 1 x Power Cord
- 1 x User’s Manual (English)
